Triple 60mA Linear LED Controller
Preliminary Information - Jan 21, 2015
E522.84/85/86/87
Common dimensions
Description
Symbol
mm
typ
inch
min
max
min
typ
max
Package height
Stand off
A
A1
A2
b
--
--
--
--
--
1.70
0.15
--
--
--
--
--
--
0.067
0.006
--
0.00
1.25
0.31
0.000
0.049
0.012
Package body thickness
Width of terminal leads, inclusive lead finish
0.51
0.020
Thickness of terminal leads, inclusive lead
finish
c
0.10
--
0.25
0.004
--
0.010
Package length
Package width
Package body width
Lead pitch
D
E
4.900 BSC
6.000 BSC
3.900 BSC
1.270 BSC
0.193 BSC
0.236 BSC
0.154 BSC
0.050 BSC
E1
e
Length of terminal for soldering to substrate
Body chamfer (45°)
L
h
0.4
0.25
0
--
--
--
--
8
1.27
0.50
8
0.016
0.010
0
--
--
--
--
8
0.050
0.020
8
Angle of lead mounting area
Mold release angle
phi [°]
phi1 [°]
N
5
15
5
15
Number of terminal positions
Variable dimensions
Assembler
C
L1
L2
V
C
L1
L2
V
Exposed pad length
Exposed pad width
D1 (BSC)
E2 (BSC)
3,302
2,286
2,667
1,778
1,651
1,651
3,099
2,413
0,130
0,090
0,105
0,070
0,065
0,065
0,122
0,095
Note: the mm values are valid, the inch values contains rounding errors
7 Functional Safety
The development of this product is based on a process according to an ISO/TS16949 certified quality management system.
Functional safety requirements according to ISO 26262 have not been submitted to Elmos and therefore have not been con-
sidered for the development of this product.
This document contains information on a pre-production product. Elmos Semiconductor AG reserves the right to change specifications and information herein without notice.
Elmos Semiconductor AG
Data Sheet
QM-No.: 25DS0137E.00
18/20
ELMOS [ ELMOS SEMICONDUCTOR AG ]
