BAS16-13-F图片预览
型号: BAS16-13-F
PDF下载: 下载PDF文件 查看货源
内容描述: [Rectifier Diode, 1 Element, 0.2A, 75V V(RRM), Silicon, GREEN, PLASTIC PACKAGE-3]
分类和应用: 光电二极管
文件页数/大小: 4 页 / 150 K
品牌: DIODES [ DIODES INCORPORATED ]
 浏览型号BAS16-13-F的Datasheet PDF文件第2页浏览型号BAS16-13-F的Datasheet PDF文件第3页浏览型号BAS16-13-F的Datasheet PDF文件第4页
BAS16 / MMBD4148 / MMBD914
SURFACE MOUNT SWITCHING DIODE
Features
Mechanical Data
Fast Switching Speed
Case: SOT23
Surface Mount Package Ideally Suited for Automated Insertion
For General Purpose Switching Applications
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Alloy 42 leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Notes 3 & 4)
Qualified to AEC-Q101 Standards for High Reliability
e3
Weight: 0.008 grams (approximate)
SOT23
Top View
Top View
Internal Schematic
Ordering Information (Note 5)
Part Number
BAS16-7-F
BAS16-13-F
Compliance
Standard
Standard
Automotive
Automotive
Standard
Standard
Standard
Standard
Case
Packaging
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
SOT23
3,000/Tape & Reel
10,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
3,000/Tape & Reel
10,000/Tape & Reel
BAS16Q-7-F
BAS16Q-13-F
MMBD4148-7-F
MMBD4148-13-F
MMBD914-7-F
MMBD914-13-F
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Product manufactured with Date Code 9W (week 39, 2009) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code 9W are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
K = SAT (Shanghai Assembly / Test site)
C = CAT (Chengdu Assembly / Test site)
A2 = Product Type Marking Code
A2 = Product Type Marking Code
YM = Date Code Marking for SAT
Y = Year (ex: A = 2013)
KA2
= Date Code Marking for CAT
CA2
YM
= Year (ex: A = 2013)
Y
M = Month (ex: 9 = September)
M = Month (ex: 9 = September)
Date Code Key
Year
2002
2003
…..
…..
2007
2008
2009
2010
2011
2012
2013
2014
2015
2016
Code
N
P
U
V
W
X
Y
Z
A
B
C
D
Month
Code
Jan
1
Feb
2
Mar
3
Apr
4
May
5
Jun
6
Jul
7
Aug
8
Sep
9
Oct
O
Nov
N
Dec
D
1 of 4
www.diodes.com
October 2013
© Diodes Incorporated
BAS16 / MMBD4148 / MMBD914
Document number: DS12003 Rev. 29 - 2
