BCM4339 Preliminary Data Sheet
WLAN Current Consumption
Table 50: Typical WLAN Current Consumption (BCM4339 Current Only) (Cont.)
VBAT = 3.6V, VDDIO = 1.8V, TA 25°C
Bandwidth
(MHz)
Band
(GHz)
Mode
Vbat, mA
Vioa, µA
Active Modes with External PAs (TX Output Power is –5 dBm at the Chip Port)
Transmit, CCK
20
20
2.4
2.4
88
76
5
5
Transmit, MCS8, HT20, SGIe, h
Transmit, MCS7, SGIe, h
Transmit, MCS7e, h
Transmit, MCS9, SGIe, h
Transmit, MCS9, SGIe, h
20
40
40
80
5
5
5
5
111
125
125
147
5
5
5
5
Active Modes with Internal PAs (TX Output Power Measured at the Chip Port)
TX CCK 11 Mbps at 21.7 dBm
20
2.4
2.4
5
325
240
280
340
270
270
5
5
5
5
5
5
TX OFDM MCS8 (SGI) at 17.2 dBm 20
TX OFDM MCS7 (SGI) at 18.5 dBm 20
TX OFDM MCS7 at 18.7 dBm
40
5
TX OFDM MCS9 (SGI) at 16.2 dBm 40
TX OFDM MCS9 (SGI) at 15.7 dBm 80
5
5
a. VIO is specified with all pins idle (not switching) and not driving any loads.
b. WL_REG_ON, BT_REG_ON low.
c. Idle, not associated, or inter-beacon.
d. Beacon Interval = 102.4 ms. Beacon duration = 1 ms @1 Mbps. Average current over the specified DTIM
intervals.
e. Measured using packet engine test mode.
f. Duty cycle is 100%. Carrier sense (CS) detect/packet receive.
g. Carrier sense (CCA) when no carrier present.
h. Duty cycle is 100%. Excludes external PA contribution.
Broadcom®
November 17, 2014 • 4339-DS106-R
Page 157
