BCM4339 Preliminary Data Sheet
General Spurious Emissions Specifications
Table 43: WLAN 5 GHz Transmitter Performance Specifications (Cont.)
Parameter
Condition/Notes
Minimum Typical Maximum Unit
Closed loop TX power
Across full-temperature and voltage
–
–
±2.0
dB
variation at highest power range. Applies across 10 to 20 dBm
level setting
output power range.
Carrier suppression
Gain control step
Return loss
–
15
–
–
–
–
–
dBc
dB
–
0.25
6
Zo = 50ꢀ
–
dB
a. The cellular standards listed indicate only typical usages of that band in some countries. Other standards may
also be used within those bands.
b. Derate by 1.5 dB for temperatures less than –10°C or more than 55°C, or voltages less than 3.0V. Derate by 3.0
dB for voltages of less than 2.7V, or voltages of less than 3.0V at temperatures less than –10°C or greater than
55°C. Derate by 4.5 dB for –40°C to –30°C.
c. TX power for Channel 1 and Channel 11 is specified by non-volatile memory parameters.
General Spurious Emissions Specifications
Table 44: General Spurious Emissions Specifications
Parameter
Condition/Notes
Min. Typ.
Max.
Unit
Frequency range
–
2400
–
2500
MHz
General Spurious Emissions
TX emissions
30 MHz < f < 1 GHz
RBW = 100 kHz
1 GHz < f < 12.75 GHz RBW = 1 MHz
1.8 GHz < f < 1.9 GHz RBW = 1 MHz
5.15 GHz < f < 5.3 GHz RBW = 1 MHz
–
–
–
–
–
–
–93
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
–45.5
–72
–87
RX/standby emissions 30 MHz < f < 1 GHz
RBW = 100 kHz
–107
–65a
–87
1 GHz < f < 12.75 GHz RBW = 1 MHz
1.8 GHz < f < 1.9 GHz RBW = 1 MHz
5.15 GHz < f < 5.3 GHz RBW = 1 MHz
–
–
–
–
dBm
dBm
–100
a. The value presented in this table is the result of LO leakage at 3/2 * fc for 2.4 GHz or 2/3 * fc for 5 GHz (where
fc is the carrier frequency). For all other emissions in this range, the value is –96 dBm.
Broadcom®
November 17, 2014 • 4339-DS106-R
Page 150
