BCM4339 Preliminary Data Sheet
WLAN 5 GHz Receiver Performance Specifications
Table 42: WLAN 5 GHz Receiver Performance Specifications (Cont.)
Parameter
Condition/Notes
Minimum Typical Maximum Unit
RX sensitivity
20 MHz channel spacing for all MCS rates
IEEE 802.11ac
(10% PER for 4096 octet
PSDU)a
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
MCS8
–
–93.3
–90.3
–87.9
–84.9
–81.4
–76.7
–75.1
–74.6
–70.2
–
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
–
–
–
–
–
–
–
–
Defined for default
parameters: 800 ns GI and
non-STBC.
RX sensitivity
40 MHz channel spacing for all MCS rates
IEEE 802.11ac
(10% PER for 4096 octet
PSDU)a
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
MCS8
MCS9
–
–90.5
–87.4
–85.3
–82.1
–79
–
–
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
–
–
–
–
–
–
–
–
–
Defined for default
parameters: 800 ns GI and
non-STBC.
–73.9
–72.4
–72.3
–67.9
–66.6
RX sensitivity
80 MHz channel spacing for all MCS rates
IEEE 802.11ac
(10% PER for 4096 octet
PSDU)a
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
MCS8
MCS9
–
–87
–
–
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
–
–
–
–
–
–
–
–
–
–83.9
–81.9
–78.1
–75
Defined for default
parameters: 800 ns GI and
non-STBC.
–73
–68.5
–68.5
–64.3
–62.7
Broadcom®
November 17, 2014 • 4339-DS106-R
Page 146
