BCM4339 Preliminary Data Sheet
Bluetooth RF Specifications
Table 34: Bluetooth Receiver RF Specifications (Cont.)
Conditions Minimum Typical
Parameter
Maximum Unit
Spurious Emissions
30 MHz–1 GHz
1–12.75 GHz
–95
–62
–47
dBm
–70
dBm
851–894 MHz
925–960 MHz
1805–1880 MHz
1930–1990 MHz
2110–2170 MHz
–147
–147
–147
–147
–147
dBm/Hz
dBm/Hz
dBm/Hz
dBm/Hz
dBm/Hz
a. The maximum value represents the actual Bluetooth specification required for Bluetooth qualification as defined
in the version 4.1 specification.
b. Bluetooth reference level is taken at the 3 dB RX desense on each of the modulation schemes.
c. Interferer: 2380 MHz, BW=10 MHz; measured at 2480 MHz.
d. Interferer: 2355 MHz, BW=10 MHz; measured at 2480 MHz.
e. Interferer: 2560 MHz, BW=10 MHz; measured at 2480 MHz.
f. Interferer: 2360 MHz, BW=10 MHz; measured at 2402 MHz.
Table 35: Bluetooth Transmitter RF Specifications
Parameter
Conditions
Minimum Typical Maximum Unit
Note: The specifications in this table are measured at the chip port output unless otherwise specified.
General
Frequency range
2402
11.0
8.0
8.0
2
2480
MHz
dBm
dBm
dBm
dB
Basic rate (GFSK) TX power at Bluetooth
QPSK TX Power at Bluetooth
8PSK TX Power at Bluetooth
Power control step
13.0
10.0
10.0
4
8
Note: Output power is with TCA and TSSI enabled.
GFSK In-Band Spurious Emissions
–20 dBc BW
0.93
1
MHz
EDR In-Band Spurious Emissions
1.0 MHz < |M – N| < 1.5 MHz
M – N = the frequency range for –
–38
–31
–43
–26.0
–20.0
–40.0
dBc
which the spurious emission is
1.5 MHz < |M – N| < 2.5 MHz
dBm
dBm
measured relative to the
transmit center frequency.
|M – N| 2.5 MHza
Broadcom®
November 17, 2014 • 4339-DS106-R
Page 130
