BCM4339 Preliminary Data Sheet
Bluetooth RF Specifications
Section 15: Bluetooth RF Specifications
Unless otherwise stated, limit values apply for the conditions specified in Table 31: “Environmental Ratings,” on
page 123 and Table 33: “Recommended Operating Conditions and DC Characteristics,” on page 124. Typical
values apply for the following conditions:
•
•
VBAT = 3.6V
Ambient temperature +25°C
Figure 41: Port Locations for Bluetooth Testing
BCM4339
RF Switch
(0.5 dB typical insertion loss)
WLAN Tx
BT Tx
Filter
WLAN/BT Rx
Antenna
Port
RF Port
Chip
Port
Note: All Bluetooth specifications are measured at the chip port unless otherwise specified.
Broadcom®
November 17, 2014 • 4339-DS106-R
Page 126
