BCM4330 Preliminary Data Sheet
WLAN 5 GHz Transmitter Performance Specifications
WLAN 5 GHz Transmitter Performance Specifications
Note: The specifications in Table 37 are measured at the chip port, unless otherwise specified.
Table 37: WLAN 5 GHz Transmitter Performance Specifications
Parameter
Condition/Notes
Minimum Typical Maximum Unit
Frequency range
–
4900
–
5845
MHz
Transmitted power in
76–108 MHz
776–794 MHz
869–960 MHz
FM Rx
–
cdmaOne,
GSM850
–
–
–
–162
–162
–162
–
–
–
dBm/Hz
dBm/Hz
dBm/Hz
cellular and FM bands (at
a
18 dBm)
925–960 MHz
1570–1580 MHz GPS
1805–1880 MHz GSM1800
1930–1990 MHz GSM1900,
cdmaOne,
E-GSM
–
–
–
–
–162
–162
–162
–162
–
–
–
–
dBm/Hz
dBm/Hz
dBm/Hz
dBm/Hz
WCDMA
2110–2170 MHz WCDMA
2400–2483 MHz BT/WLAN
9.8–11.570 GHz 2nd harmonic
–
–
–
–162
–162
–31
–
–
–
dBm/Hz
dBm/Hz
dBm/MHz
Harmonic level
(at 17 dBm)
EVM Does Not Exceed
Tx power for highest
power level setting at
25°C, VBATT = 3.6V and
spectral mask and EVM
OFDM, BPSK
OFDM, 64-QAM –25 dB
(R = 3/4)
OFDM, 64-QAM –28 dB
(R = 5/6)
–8 dB
–
–
14
14
–
–
dBm
dBm
b
–
12.5
–
dBm
dB
compliance
Tx power control dynamic –
range
Tx power control
resolution
Closed loop Tx power
variation at highest power range
level setting
10
0.5
–
–
–
–
–
–
–
dB
Across full temperature and voltage
±2
dB
Carrier suppression
Gain control step
Return loss
–
–
15
–
–
–
0.25
6
–
–
–
dBc
dB
dB
Zo = 50Ω
®
BROADCOM
BCM4330 Preliminary Data Sheet
April 28, 2011 • 4330-DS304-RI
Page 141
