BCM4330 Preliminary Data Sheet
Bluetooth RF Specifications
Table 30: Local Oscillator Performance
Minimum Typical
Parameter
Maximum Unit
LO Performance
Lock time
Initial carrier frequency tolerance
–
–
72
±25
–
±75
µs
kHz
Frequency Drift
DH1 packet
DH3 packet
DH5 packet
Drift rate
–
–
–
–
25
40
40
6
±25
±40
±40
20
kHz
kHz
kHz
kHz/50 µs
Frequency Deviation
a
00001111 sequence in payload
140
115
–
147
138
1
175
–
–
kHz
kHz
MHz
b
10101010 sequence in payload
Channel spacing
a. This pattern represents an average deviation in payload.
b. Pattern represents the maximum deviation in payload for 99.9% of all frequency deviations.
®
