CUI Devices │ SERIES: CFM-60V │ DESCRIPTION: DC AXIAL FAN
date 02/11/2020 │ page 11 of 15
MECHANICAL
parameter
conditions/description
4 pole DC brushless
omniCOOLTM
min
typ
max
units
motor
bearing system
direction of rotation
counter-clockwise viewed from front of fan blade
CFM-6010V models: 60 x 60 x 10
CFM-6015V models: 60 x 60 x 15
CFM-6020V models: 60 x 60 x 20
CFM-6025V models: 60 x 60 x 25
mm
mm
mm
mm
dimensions
material
weight
PBT (UL94V-0)
CFM-6010V models
CFM-6015V models
CFM-6020V models
CFM-6025V models
23
35.5
50
g
g
g
g
45
MECHANICAL DRAWINGS
units: mm
MOUNTING SCREW (Pan Head)
Screw Type
Machine Screw
Size
M4
Standard
Torque
wire: UL 1007, 26 AWG
JIS B1111-1974 3~4 kgf-cm
JIS B1122 Type 2 5~6 kgf-cm
Self-tapping Screw
M5
CFM-6010V
WIRE CONNECTIONS
Wire Color
Red
Function
+Vin
Black
-Vin
White1
Yellow1
RD Signal
Tach Signal
CFM-6015V
WIRE CONNECTIONS
Wire Color
Red
Function
+Vin
Black
-Vin
White1
Yellow1
RD Signal
Tach Signal
Notes: 1. Wires only present on versions with output signals.
