KP3020 Series
8PIN PHOTOTRANSISTOR
PHOTOCOUPLER
cosmo
Outside Dimension
Unit : mm
1.Dual-in-line type.
2.Surface mount type.
KP3020
KP3020S
7.62
6.50
9.68
7.62
6.50
9.68
0~10°
1.00
1.20
10.00±0.4
0.25
2.54
0.50
2.54
1.20
13.00°
13.00°
4.Long creepage distance
for surface mount type.
3.Long creepage distance type
KP3020H
KP3020L
10.16
7.62
6.50
9.68
7.62
6.50
9.68
0~10°
0.90±0.25
0.90±0.25
+0.2
-0.5
2.54
11.80
1.20
0.25
10.16±0.50
1.20
0.50
2.54
2.54
TOLERANCE：±0.2mm
Device Marking
Notes:
cosmo
3020
cosmo
3020
YWW
Y: Year code / WW: Week code
YWW
Cosmo Electronics Corp.
Document No. 69P12001.2
http://www.cosmo-ic.com
- 2 -
