KP3020 Series
8PIN PHOTOTRANSISTOR
PHOTOCOUPLER
cosmo
Numbering System
KP3020 X Y (Z)
Notes:
KP3020 = Part No.
X = Lead form option (0,S,H,L)
Y = CTR rank ( A, B)
Z = Tape and reel option (TL,TR,TLD,TRU)
Option
Description
Packing quantity
S (TL)
S (TR)
L (TLD)
L (TRU)
surface mount type package + TL tape & reel option
surface mount type package + TR tape & reel option
1000 units per reel
1000 units per reel
1000 units per reel
1000 units per reel
long creepage distance for surface mount type package +
TLD tape & reel option
long creepage distance for surface mount type package +
TRU tape & reel option
Recommended Pad Layout for Surface Mount Lead Form
2.Long creepage distance
for surface mount type.
8 pin L
1.Surface mount type.
8 pin SMD
Unit : mm
