CS4351
2. CHARACTERISTICS AND SPECIFICATIONS
(Min/Max performance characteristics and specifications are guaranteed over the Specified Operating Conditions.
Typical specifications are derived from performance measurements at T = 25 °C, VA_H = 12 V, VA = 3.3 V,
A
VD = 3.3 V.)
SPECIFIED OPERATING CONDITIONS
(GND = 0 V; all voltages with respect to ground.)
Parameters
Symbol
Min
Typ
Max
Units
DC Power Supply
High Voltage Analog power
Low Voltage Analog power
Digital power
VA_H
VA
VD
8.55
3.13
3.13
1.7
12
3.3
3.3
3.3
12.6
3.47
3.47
3.47
V
V
V
V
Interface power
VL
Specified Temperature Range
-CZZ
-DZZ
TA
TA
-10
-40
-
-
70
85
°C
°C
ABSOLUTE MAXIMUM RATINGS
(GND = 0 V; all voltages with respect to ground.)
Parameters
Symbol
Min
Max
Units
DC Power Supply
High Voltage Analog power
Low Voltage Analog power
Digital power
VA_H
VA
VD
-0.3
-0.3
-0.3
-0.3
14
V
V
V
V
3.63
3.63
3.63
Interface power
VL
Input Current, Any Pin Except Supplies
Digital Input Voltage
Iin
VIN-L
TA
-
±10
VL+ 0.4
125
mA
V
Digital Interface
-0.3
-55
-65
Ambient Operating Temperature (power applied)
Storage Temperature
°C
°C
Tstg
150
Operation at or beyond these limits may result in permanent damage to the device. Normal operation is not guar-
anteed at these extremes.
6
DS566F1
