Data Sheet
LOW POWER LOW OFFSET VOLTAGE DUAL COMPARATORS
AZ393/393C
Absolute Maximum Ratings (Note 1)
Parameter
Symbol
VCC
VID
Value
20
Unit
V
Supply Voltage
Differential Input Voltage
Input Voltage
20
V
VIN
-0.3 to 20
50
V
IIN
Input Current (V < -0.3V) (Note 2)
mA
IN
DIP-8
780
660
Power Dissipation (TA=25oC)
PD
mW
SOIC-8
Output Short Circuit to Ground
Operating Junction Temperature
Storage Temperature Range
Continuous
150
o
TJ
C
o
TSTG
TLEAD
-65 to 150
C
o
Lead Temperature (Soldering, 10 seconds)
260
C
Note 1: Stresses greater than those listed under "Absolute Maximum Ratings" may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Max-
imum Ratings" for extended periods may affect device reliability.
Note 2: This input current will only exist when the voltage at any of the input leads is driven negative. It is due to
the collector-base junction of the input PNP transistors becoming forward biased and thereby acting as input
diode clamps. In addition to this diode action, there is also lateral NPN parasitic transistor action on the IC chip.
This transistor action can cause the output voltages of the comparators to go to the V+ voltage level (or to ground
for a large overdrive) for the time duration that an input is driven negative. This is not destructive and normal out-
put states will re-establish when the input voltage, which was negative, again returns to a value greater than -0.3
o
V
(at 25 C).
DC
Recommended Operating Conditions
Symbol
Parameter
Min
2
Max
18
Unit
VCC
Supply Voltage
V
o
Operating Temperature Range
-40
85
TA
C
Aug. 2006 Rev. 1. 2
