PCM3793A
PCM3794A
www.ti.com
SLAS529A–JANUARY 2007–REVISED FEBRUARY 2007
Register 88
B15
0
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
MXL0
Register 88
IDX6
IDX5
IDX4
IDX3
IDX2
IDX1
IDX0
RSV
MXR2
MXR1
MXR0
RSV
MXL2
MXL1
IDX[6:0]: 101 1000b (58h): Register 88
MXR2: Mixing SW6 to MXR (R-Channel Mixing Amplifier) From L-Channel Analog Input
Default value: 0
This bit is used to mix the analog source into MXR (R-ch mixing amplifier) from the L-ch analog input.
MXR2 = 0
MXR2 = 1
Disable (default)
Enable
MXR1: Mixing SW4 to MXR (R-Channel Mixing Amplifier) From R-Channel Analog Input
Default value: 0
This bit is used to mix the analog source into MXR (R-ch mixing amplifier) from the R-ch analog input.
MXR1 = 0
MXR1 = 1
Disable (default)
Enable
MXR0: Mixing SW5 to MXR (R-Channel Mixing Amplifier) From R-Channel DAC
Default value: 0
This bit is used to mix the analog source into MXR (R-ch mixing amplifier) from the R-ch DAC.
MXR0 = 0
MXR0 = 1
Disable (default)
Enable
MXL2: Mixing SW3 to MXL (L-Channel Mixing Amplifier) From R-Channel Analog Input
Default value: 0
This bit is used to mix the analog source into MXL (L-ch mixing amplifier) from the R-ch analog input.
MXL2 = 0
MXL2 = 1
Disable (default)
Enable
MXL1: Mixing SW1 to MXL (L-Channel Mixing Amplifier) From L-Channel Analog Input
Default value: 0
This bit is used to mix the analog source into MXL (L-ch mixing amplifier) from the L-ch analog input.
MXL1 = 0
MXL1 = 1
Disable (default)
Enable
MXL0: Mixing SW2 to MXL (L-Channel Mixing Amplifier) From L-Channel DAC
Default value: 0
This bit is used to mix the analog source into MXL (L-ch mixing amplifier) from the L-ch DAC.
MXL0 = 0
MXL0 = 1
Disable (default)
Enable
