PCMCIA PC Memory Card Connectors
Series 5025 Product Selection Guide
SERIES 5025
CONNECTOR
EJECTOR
RIGHT SIDE
LEFT SIDE
DUAL DIP/DIP
Connector Style
Ejector Style
Button Side
Left/Left
Right/Right
Left/Right
Right/Left
Left/Left
Right/Right
Left/Right
Right/Left
Assembly Number
Connector
How To Order
Page
Stand Off Voltage
Keying
Normal
Ejector
Height=0
5v
31 5025 136 500 871
31 5025 136 500 871
31 5025 136 500 871
31 5025 136 500 871
31 5025 136 550 871
31 5025 136 550 871
31 5025 136 550 871
31 5025 136 550 871
30 5025 000 621 000
30 5025 000 622 000
30 5025 000 623 000
30 5025 000 624 000
30 5025 000 621 000
30 5025 000 622 000
30 5025 000 623 000
30 5025 000 624 000
10, 11
Height=0
5v
Reverse
10, 11
Note – If drawings are required then please contact your local sales office.
Assembly number for connector above comprises of a lower and upper header that
needs to be ordered separately. See below on How To Order.
Assembly Number
Header Type
Upper Header
Lower Header
Upper Header
Lower Header
How To Order
Page
31 5025 068 200 871
31 5025 068 100 871
31 5025 068 250 871
31 5025 068 150 871
31 5025 136 500 871
10, 11
31 5025 136 550 871
10, 11
5
