PCMCIA PC Memory Card Connectors
Features/Benefits
SERIES 5025
Series 5025 offers single or double stacked header combinations in SMT
or Through Hole.
Also, this series meets the requirements of Ver. 4.2/PCMCIA Type I, II and
III equipment.
Upper and lower stage of header offers the combination of DIP/SMT and
DIP/DIP.
TECHNICAL SPECIFICATIONS
Number of Contacts:
Pitch:
68, 136 (with ESD terminal)
1.27mm (0.05)
0.5A Max.
Current Rating:
Voltage Rating:
DW Voltage:
5V Max.
500V rms/min.
10,000
Mating Cycles
SERIES 5027
This is an SMT lightweight connector for 3.3v or 5v cards.
Height is 5.0mm (0.197), weight is under 10 grams (with single ejector
mechanism) which is one of the lightest available in this industry.
Dual type is 2 pcs, side-by-side configuration and you can choose
“With Ejector type” or “Without Ejector type”.
This meets the requirements of PCMCIA, Type I, II and III.
TECHNICAL SPECIFICATIONS
Number of Contacts:
Pitch:
68, 136
1.27mm (0.05)
0.5A Max.
5V Max.
Current Rating:
Voltage Rating:
DW Voltage:
500V rms/min.
10,000
Mating Cycles
SERIES 5069
1.27mm (0.05) pitch 68 positions plug connector designed for PC card.
Contacts on the card side is arranged in two rows and the substrate
side has DIP type and SMT type.
Receptacle (card side) connector is also available.
TECHNICAL SPECIFICATIONS
Number of Contacts:
Pitch:
68
1.27mm (0.05)
0.5A Max.
5V Max.
Current Rating:
Voltage Rating:
DW Voltage:
500V rms/min.
10,000
Mating Cycles
SERIES 9170
9170 Series is the PC card connector. It complies with JEIDA/PCMCIA
Type II.
Greatest PCB # spacing available in the market allowing design engineer
to compact more electronics components onto the PCB board.
Assembly tooling can be supplied to reduce OEM cycle time.
Top/Bottom cover has a unique patented interlocking mechanism, which
offers a Robust construction.
Complete I/O connection system is available.
Dedicated I/O connector offered with options of with/without co-axial
contacts or Blank I/O.
3
