PCMCIA PC Memory Card Connectors
Series 9170 PCMCIA Type II Frameless Card Kit
Assembly Tooling
FEATURES
FRAMELESS KIT ASSEMBLY TOOL
06-9170-7010-00-000
•
•
•
Semi-Automatic Tooling
User friendly - no special operator skills required
Tooling can be modified for Elco extended card solutions
HOW TO ORDER
06
9170
7010
00
000
PRODUCTION TOOLING FOR
FRAMELESS KIT 9170 SERIES
This is Semi-Automatic Tooling
Approximate Cycle Time = approx. 3 complete kits per minute
= 3 x 60
= 180/per hour
Assume: 8 Hour Shift
= 180 x 8
= 1,400/per shift
Assume: 20 days
per Month
= 1,400 x 20
= 28,800/per month
MINIMUM: 28,800 x 12 = 345,600/per annum
29
