PCMCIA PC Memory Card Connectors
Series 9170 PCMCIA Type II Frameless Card Kit I/O Connector
FEATURES
•
•
•
•
Elco can offer its unique self-cleaning contact technology
Recess provided for latching mechanism
Keying is incorporated to prevent incorrect insertion
Surface mount technology used for easy pick and
place assembly
•
•
Can be pre-assembled to PCB board before reflow
Optional flexibility offered with switching co-axial and
without co-axial
STANDARD I/O CONNECTOR WITHOUT CO-AXIAL
STANDARD I/O CONNECTOR WITH CO-AXIAL
HOW TO ORDER
21
9170
015
00X
XXX
001=Without co-axial 001=Tray - 576
002=With co-axial 002=Tape & Reel - 576
003=Tube - 144
25
