Product Specification
M270DTN01.5
2. General Description
This specification applies to the 27 inch-FHD Color a-Si TFT-LCD Module M270DTN01.5.The
display supports the QHD - 2560(H) x 1440(V) screen format and 16.7M colors (RGB 8-bits data). The
input interface is 8 port LVDS and this module doesn’t contain a driver board for backlight.
Display Characteristics
The following items are characteristics summary on the table under 25℃ condition:
ITEMS
Unit
SPECIFICATIONS
Screen Diagonal
mm
684.67(27.0”)
Active Area
mm
um
596.74 (H) x 335.66 (V)
2560(x3) x 1440
Pixels H x V
Pixel Pitch
233.1 (per one triad) ×233.1
R.G.B. Vertical Stripe
TN Mode, Normally White
350 cd/m2 (Typ.)
Pixel Arrangement
Display Mode
White Luminance ( Center )
Contrast Ratio
cd/m2
1000(Typ.)
Optical Response Time
msec
Watt
5ms (Typ., on/off)
33.8 W
Power Consumption
(VDD line + LED line)
LCD module:PDD(Typ)=6.5 @Black pattern Fv=144 Hz
Backlight unit:PBLu(Typ)=27.3 @Is=120mA
Color gamut
%
72
Weight
Grams
mm
2500 (Typ.)
Outline Dimension
Electrical Interface
Support Color
Surface Treatment
609.00(H)x354.66(V)x11.60(D)
8 port LVDS
16.7M colors (RGB 8-bit )
Anti-Glare, 3H
Temperature Range
Operating
Storage (Shipping)
oC
oC
0 to +50
-20 to +60
RoHS Compliance
TCO Compliance
RoHS Compliance
TCO 6.0 Compliance
5
