ATtiny2313/V
System Clock and
Clock Options
Clock Systems and their Figure 11 presents the principal clock systems in the AVR and their distribution. All of
the clocks need not be active at a given time. In order to reduce power consumption, the
Distribution
clocks to modules not being used can be halted by using different sleep modes, as
described in “Power Management and Sleep Modes” on page 29. The clock systems
are detailed below.
Figure 11. Clock Distribution
General I/O
Modules
Flash and
EEPROM
CPU Core
RAM
clkI/O
clkCPU
AVR Clock
Control Unit
clkFLASH
Reset Logic
Watchdog Timer
Source clock
Watchdog clock
Clock
Multiplexer
Watchdog
Oscillator
Crystal
Oscillator
Calibrated RC
Oscillator
External Clock
CPU Clock – clkCPU
I/O Clock – clkI/O
The CPU clock is routed to parts of the system concerned with operation of the AVR
core. Examples of such modules are the General Purpose Register File, the Status Reg-
ister and the data memory holding the Stack Pointer. Halting the CPU clock inhibits the
core from performing general operations and calculations.
The I/O clock is used by the majority of the I/O modules, like Timer/Counters, and
USART. The I/O clock is also used by the External Interrupt module, but note that some
external interrupts are detected by asynchronous logic, allowing such interrupts to be
detected even if the I/O clock is halted. Also note that start condition detection in the USI
module is carried out asynchronously when clkI/O is halted, enabling USI start condition
detection in all sleep modes.
Flash Clock – clkFLASH
The Flash clock controls operation of the Flash interface. The Flash clock is usually
active simultaneously with the CPU clock.
