grammed, the Reset Vector will always point to the Boot Loader Reset and the fuse can only be
changed through the serial or parallel programming interface.
Table 26-4. Boot Reset Fuse(1)
BOOTRST
Reset Address
1
0
Reset Vector = Application Reset (address 0x0000)
Reset Vector = Boot Loader Reset (see Table 26-6 on page 292)
Note:
1. “1” means unprogrammed, “0” means programmed
26.7 Addressing the Flash During Self-programming
• The Z-pointer is used to address the SPM commands.
Bit
15
Z15
Z7
7
14
Z14
Z6
6
13
Z13
Z5
5
12
Z12
Z4
4
11
Z11
Z3
3
10
Z10
Z2
2
9
Z9
Z1
1
8
Z8
Z0
0
ZH (R31)
ZL (R30)
Since the Flash is organized in pages (see Table 27-9 on page 300), the Program Counter can
be treated as having two different sections. One section, consisting of the least significant bits, is
addressing the words within a page, while the most significant bits are addressing the pages.
This is shown in Figure 26-3. Note that the Page Erase and Page Write operations are
addressed independently. Therefore, it is of major importance that the Boot Loader software
addresses the same page in both the Page Erase and Page Write operation. Once a program-
ming operation is initiated, the address is latched and the Z-pointer can be used for other
operations.
The only SPM operation that does not use the Z-pointer is Setting the Boot Loader Lock bits.
The content of the Z-pointer is ignored and will have no effect on the operation. The LPM
instruction does also use the Z-pointer to store the address. Since this instruction addresses the
Flash byte-by-byte, also the LSB (Bit Z0) of the Z-pointer is used.
