Internal Clock Generation – The Baud Rate Generator
Internal clock generation is used for the asynchronous and the synchronous master modes of
operation. The description in this section refers to Figure 20-2.
The USART Baud Rate Register n (UBRRn) and the down-counter connected to it function as a
programmable prescaler or baud rate generator. The down-counter, running at system clock
(fOSC), is loaded with the UBRRn value each time the counter has counted down to zero or when
the UBRRnL Register is written. A clock is generated each time the counter reaches zero. This
clock is the baud rate generator clock output (= fOSC/(UBRRn+1)). The transmitter divides the
baud rate generator clock output by 2, 8, or 16 depending on mode. The baud rate generator
output is used directly by the receiver’s clock and data recovery units. However, the recovery
units use a state machine that uses 2, 8 or 16 states depending on mode set by the state of the
UMSELn, U2Xn and DDR_XCK bits.
Table 20-1 contains equations for calculating the baud rate (in bits per second) and for calculat-
ing the UBRRn value for each mode of operation using an internally generated clock source.
Table 20-1. Equations for Calculating Baud Rate Register Setting
Equation for Calculating
Baud Rate(1)
Equation for Calculating
UBRR Value
Operating Mode
Asynchronous Normal
mode (U2Xn = 0)
f
OSC
f
OSC
BAUD = -----------------------------------------
UBRRn = ----------------------- – 1
16(UBRR + 1n)
16BAUD
Asynchronous Double
Speed mode (U2Xn = 1)
f
OSC
f
OSC
BAUD = --------------------------------------
UBRRn = -------------------- – 1
8(UBRRn + 1)
8BAUD
Synchronous Master
mode
f
OSC
f
OSC
BAUD = --------------------------------------
UBRRn = -------------------- – 1
2(UBRR + 1n)
2BAUD
Note:
1. The baud rate is defined to be the transfer rate in bit per second (bps).
BAUD
Baud rate (in bits per second, bps)
fOSC
System Oscillator clock frequency
UBRR
Contents of the UBRRnH and UBRRnL Registers, (0 - 4095)
Some examples of UBRRn values for some system clock frequencies are found in Table 20-4 on
page 192 to Table 20-7 on page 195.
20.3.2
Double Speed Operation (U2Xn)
The transfer rate can be doubled by setting the U2Xn bit in UCSRnB. Setting this bit only has
effect for the asynchronous operation. Set this bit to zero when using synchronous operation.
Setting this bit will reduce the divisor of the baud rate divider from 16 to 8, effectively doubling
the transfer rate for asynchronous communication. Note however that the Receiver will in this
case only use half the number of samples (reduced from 16 to 8) for data sampling and clock
recovery, and therefore a more accurate baud rate setting and system clock are required when
this mode is used. For the Transmitter, there are no downsides.
