ATmega8(L)
Changes from Rev. 1. Updated Table 98 on page 233.
2486S- 08/07 to
2. Updated “Ordering Information” on page 314.
Rev. 2486T- 05/08
- Commercial Ordering Code removed.
- No Pb-free packaging option removed.
Changes from Rev. 1. Updated “Features” on page 1.
2486R- 07/07 to
2. Added “Data Retention” on page 7.
Rev. 2486S- 08/07
3. Updated “Errata” on page 318.
4. Updated “Slave Mode” on page 125.
Changes from Rev. 1. Added text to Table 81 on page 211.
2486Q- 10/06 to
2. Fixed typo in “Peripheral Features” on page 1.
Rev. 2486R- 07/07
3. Updated Table 16 on page 42.
4. Updated Table 75 on page 199.
5. Removed redundancy and updated typo in Notes section of “DC Characteristics” on
page 235.
Changes from Rev. 1. Updated “Timer/Counter Oscillator” on page 32.
2486P- 02/06 to
Rev. 2486Q- 10/06
2. Updated “Fast PWM Mode” on page 88.
3. Updated code example in “USART Initialization” on page 134.
4. Updated Table 37 on page 96, Table 39 on page 97, Table 42 on page 115, Table 44 on
page 115, and Table 98 on page 233.
5. Updated “Errata” on page 318.
Changes from Rev. 1. Added “Resources” on page 7.
2486O-10/04 to
2. Updated “External Clock” on page 32.
Rev. 2486P- 02/06
3. Updated “Serial Peripheral Interface – SPI” on page 121.
4. Updated Code Example in “USART Initialization” on page 134.
5. Updated Note in “Bit Rate Generator Unit” on page 164.
6. Updated Table 98 on page 233.
7. Updated Note in Table 103 on page 241.
321
2486AA–AVR–02/2013
