ATmega8(L)
Packaging Information
32A
PIN 1 IDENTIFIER
PIN 1
B
e
E1
E
D1
D
C
0°~7°
A2
A
A1
L
COMMON DIMENSIONS
(Unit of measure = mm)
MIN
–
MAX
1.20
0.15
1.05
9.25
7.10
9.25
7.10
0.45
0.20
0.75
NOM
NOTE
SYMBOL
A
–
–
A1
A2
D
0.05
0.95
8.75
6.90
8.75
6.90
0.30
0.09
0.45
1.00
9.00
7.00
9.00
7.00
–
D1
E
Note 2
Note 2
Notes:
1. This package conforms to JEDEC reference MS-026, Variation ABA.
2. Dimensions D1 and E1 do not include mold protrusion. Allowable
protrusion is 0.25mm per side. Dimensions D1 and E1 are maximum
plastic body size dimensions including mold mismatch.
3. Lead coplanarity is 0.10mm maximum.
E1
B
C
–
L
–
e
0.80 TYP
2010-10-20
TITLE
DRAWING NO.
REV.
32A, 32-lead, 7 x 7mm body size, 1.0mm body thickness,
0.8mm lead pitch, thin profile plastic quad flat package (TQFP)
32A
C
315
2486AA–AVR–02/2013
