ATmega48/88/168
Interrupt Vectors in ATmega88
Table 27. Reset and Interrupt Vectors in ATmega88
Program
Vector No.
Address(2)
0x000(1)
0x001
0x002
0x003
0x004
0x005
0x006
0x007
0x008
0x009
0x00A
0x00B
0x00C
0x00D
0x00E
0x00F
0x010
0x011
0x012
0x013
0x014
0x015
0x016
0x017
0x018
0x019
Source
Interrupt Definition
1
RESET
External Pin, Power-on Reset, Brown-out Reset and Watchdog System Reset
External Interrupt Request 0
External Interrupt Request 1
Pin Change Interrupt Request 0
Pin Change Interrupt Request 1
Pin Change Interrupt Request 2
Watchdog Time-out Interrupt
Timer/Counter2 Compare Match A
Timer/Counter2 Compare Match B
Timer/Counter2 Overflow
2
INT0
3
INT1
4
PCINT0
5
PCINT1
6
PCINT2
7
WDT
8
TIMER2 COMPA
TIMER2 COMPB
TIMER2 OVF
TIMER1 CAPT
TIMER1 COMPA
TIMER1 COMPB
TIMER1 OVF
TIMER0 COMPA
TIMER0 COMPB
TIMER0 OVF
SPI, STC
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Timer/Counter1 Capture Event
Timer/Counter1 Compare Match A
Timer/Coutner1 Compare Match B
Timer/Counter1 Overflow
Timer/Counter0 Compare Match A
Timer/Counter0 Compare Match B
Timer/Counter0 Overflow
SPI Serial Transfer Complete
USART Rx Complete
USART, RX
USART, UDRE
USART, TX
ADC
USART, Data Register Empty
USART, Tx Complete
ADC Conversion Complete
EE READY
ANALOG COMP
TWI
EEPROM Ready
Analog Comparator
2-wire Serial Interface
SPM READY
Store Program Memory Ready
Notes: 1. When the BOOTRST Fuse is programmed, the device will jump to the Boot Loader
address at reset, see “Boot Loader Support – Read-While-Write Self-Programming,
ATmega88 and ATmega168” on page 255.
2. When the IVSEL bit in MCUCR is set, Interrupt Vectors will be moved to the start of
the Boot Flash Section. The address of each Interrupt Vector will then be the address
in this table added to the start address of the Boot Flash Section.
Table 28 shows reset and Interrupt Vectors placement for the various combinations of
BOOTRST and IVSEL settings. If the program never enables an interrupt source, the
Interrupt Vectors are not used, and regular program code can be placed at these loca-
tions. This is also the case if the Reset Vector is in the Application section while the
Interrupt Vectors are in the Boot section or vice versa.
53
2545D–AVR–07/04
