ATmega32(L)
3. Added the section “Default Clock Source” on page 25.
4. When using External Clock there are some limitations regards to change of
frequency. This is described in “External Clock” on page 31 and Table 117 on
page 289.
5. Added a sub section regarding OCD-system and power consumption in the
section “Minimizing Power Consumption” on page 34.
6. Corrected typo (WGM-bit setting) for:
– “Fast PWM Mode” on page 75 (Timer/Counter0)
– “Phase Correct PWM Mode” on page 76 (Timer/Counter0)
– “Fast PWM Mode” on page 120 (Timer/Counter2)
– “Phase Correct PWM Mode” on page 121 (Timer/Counter2)
7. Corrected Table 67 on page 164 (USART).
8. Updated VIL, IIL, and IIH parameter in “DC Characteristics” on page 287.
9. Updated Description of OSCCAL Calibration Byte.
In the datasheet, it was not explained how to take advantage of the calibration bytes
for 2, 4, and 8 MHz Oscillator selections. This is now added in the following
sections:
Improved description of “Oscillator Calibration Register – OSCCAL” on page 30 and
“Calibration Byte” on page 258.
10. Corrected typo in Table 42.
11. Corrected description in Table 45 and Table 46.
12. Updated Table 118, Table 120, and Table 121.
13. Added “Errata” on page 336.
339
2503J–AVR–10/06
