Assembly Code Example(1)
USART_Receive:
; Wait for data to be received
sbis UCSR0A, RXC0
rjmp USART_Receive
; Get status and 9th bit, then data from buffer
in
in
in
r18, UCSR0A
r17, UCSR0B
r16, UDR0
; If error, return -1
andi r18,(1<<FE0)|(1<<DOR0)|(1<<UPE0)
breq USART_ReceiveNoError
ldi r17, HIGH(-1)
ldi r16, LOW(-1)
USART_ReceiveNoError:
; Filter the 9th bit, then return
lsr r17
andi r17, 0x01
ret
C Code Example(1)
unsigned int USART_Receive( void )
{
unsigned char status, resh, resl;
/* Wait for data to be received */
while ( !(UCSRnA & (1<<RXCn)) )
;
/* Get status and 9th bit, then data */
/* from buffer */
status = UCSR0A;
resh = UCSR0B;
resl = UDR0;
/* If error, return -1 */
if ( status & (1<<FE0)|(1<<DOR0)|(1<<UPE0) )
return -1;
/* Filter the 9th bit, then return */
resh = (resh >> 1) & 0x01;
return ((resh << 8) | resl);
}
Note:
1. ”About Code Examples” on page 9
The receive function example reads all the I/O Registers into the Register File before any com-
putation is done. This gives an optimal receive buffer utilization since the buffer location read will
be free to accept new data as early as possible.
