AT90USB64/128

Table 29-17. JTAG Programming Instruction (Continued)

Set (Continued) a = address high bits, b = address low bits, c = address extended bits, H = 0 - Low byte, 1 - High Byte,

o = data out, i = data in, x = don’t care

Instruction

TDI Sequence

TDO Sequence

Notes

4g. Poll for Page Write Complete

5a. Enter EEPROM Read

5b. Load Address High Byte

5c. Load Address Low Byte

0110011_00000000

0100011_00000011

0000111_aaaaaaaa

0000011_bbbbbbbb

xxxxxox_xxxxxxxx

xxxxxxx_xxxxxxxx

(2)

(10)

0110011_bbbbbbbb

0110010_00000000

0110011_00000000

xxxxxxx_xxxxxxxx

xxxxxxx_oooooooo

5d. Read Data Byte

6a. Enter Fuse Write

0100011_01000000

xxxxxxx_xxxxxxxx

6b. Load Data Low Byte⁽⁶⁾

0010011_iiiiiiii

(3)

(1)

0111011_00000000

0111001_00000000

0111011_00000000

xxxxxxx_xxxxxxxx

6c. Write Fuse Extended Byte

6d. Poll for Fuse Write Complete

6e. Load Data Low Byte⁽⁷⁾

0110111_00000000

xxxxxox_xxxxxxxx

(2)

(3)

0010011_iiiiiiii

xxxxxxx_xxxxxxxx

0110111_00000000

0110101_00000000

0110111_00000000

xxxxxxx_xxxxxxxx

6f. Write Fuse High Byte

(1)

6g. Poll for Fuse Write Complete

6h. Load Data Low Byte⁽⁷⁾

0110111_00000000

xxxxxox_xxxxxxxx

(2)

(3)

0010011_iiiiiiii

xxxxxxx_xxxxxxxx

0110011_00000000

0110001_00000000

0110011_00000000

xxxxxxx_xxxxxxxx

6i. Write Fuse Low Byte

(1)

6j. Poll for Fuse Write Complete

7a. Enter Lock Bit Write

7b. Load Data Byte⁽⁹⁾

0110011_00000000

0100011_00100000

0010011_11iiiiii

xxxxxox_xxxxxxxx

xxxxxxx_xxxxxxxx

(2)

(4)

0110011_00000000

0110001_00000000

0110011_00000000

xxxxxxx_xxxxxxxx

7c. Write Lock Bits

(1)

(2)

7d. Poll for Lock Bit Write complete

8a. Enter Fuse/Lock Bit Read

0110011_00000000

0100011_00000100

xxxxxox_xxxxxxxx

xxxxxxx_xxxxxxxx

0111010_00000000

0111011_00000000

xxxxxxx_xxxxxxxx

8b. Read Extended Fuse Byte⁽⁶⁾

8c. Read Fuse High Byte⁽⁷⁾

xxxxxxx_oooooooo

0111110_00000000

0111111_00000000

xxxxxxx_xxxxxxxx

xxxxxxx_oooooooo

393

7593A–AVR–02/06
