and SPIF in SPSR will become set. The user will then have to set MSTR to re-enable SPI Mas-
ter mode.
• Bit 3 – CPOL: Clock Polarity
When this bit is written to one, SCK is high when idle. When CPOL is written to zero, SCK is low
when idle. Refer to Figure 17-3 and Figure 17-4 for an example. The CPOL functionality is sum-
marized below:
Table 17-2. CPOL Functionality
CPOL
Leading Edge
Rising
Trailing Edge
Falling
0
1
Falling
Rising
• Bit 2 – CPHA: Clock Phase
The settings of the Clock Phase bit (CPHA) determine if data is sampled on the leading (first) or
trailing (last) edge of SCK. Refer to Figure 17-3 and Figure 17-4 for an example. The CPOL
functionality is summarized below:
Table 17-3. CPHA Functionality
CPHA
Leading Edge
Sample
Trailing Edge
Setup
0
1
Setup
Sample
• Bits 1, 0 – SPR1, SPR0: SPI Clock Rate Select 1 and 0
These two bits control the SCK rate of the device configured as a Master. SPR1 and SPR0 have
no effect on the Slave. The relationship between SCK and the Oscillator Clock frequency fosc is
shown in the following table:
Table 17-4. Relationship Between SCK and the Oscillator Frequency
SPI2X
SPR1
SPR0
SCK Frequency
fosc/4
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
fosc/16
fosc/64
fosc/128
fosc/2
fosc/8
fosc/32
fosc/64
17.1.4
SPI Status Register – SPSR
Bit
7
6
5
–
R
0
4
–
R
0
3
–
R
0
2
–
R
0
1
–
R
0
0
SPIF
R
WCOL
SPI2X
R/W
0
SPSR
Read/Write
Initial Value
R
0
0
• Bit 7 – SPIF: SPI Interrupt Flag
