APL3512
Package Information
SOP-8
-T- SEATING PLANE < 4 mils
SEE VIEW A
D
b
c
e
GAUGE PLANE
SEATING PLANE
L
VIEW A
SOP-8
S
Y
M
B
O
L
MILLIMETERS
INCHES
MIN.
MAX.
MIN.
MAX.
A
1.75
0.25
0.069
0.004
0.049
0.012
0.007
0.010
A1
A2
b
0.10
1.25
0.31
0.17
0.020
0.010
0.51
0.25
5.00
6.20
4.00
c
D
4.80
5.80
3.80
0.189
0.228
0.150
0.197
0.244
0.157
E
E1
e
h
L
1.27 BSC
0.050 BSC
0.010
0.016
0.020
0.050
0.25
0.40
0°
0.50
1.27
8
0
8
0°
Note: 1. Follow JEDEC MS-012 AA.
2. Dimension “D” does not include mold flash, protrusions or gate burrs.
Mold flash, protrusion or gate burrs shall not exceed 6 mil per side.
3. Dimension “E” does not include inter-lead flash or protrusions.
Inter-lead flash and protrusions shall not exceed 10 mil per side.
Copyright ã ANPEC Electronics Corp.
16
www.anpec.com.tw
Rev. A.6 - Aug., 2012
