Plastic Connectors
Series 101 Solder Cup or Crimp Termination - How to Order
Amphenol
Aerospace
Qualiꢇied to M83513 (slash sheets 06 thru 09)
Example:
101R09P-4A5FM2-20
Description: Plastic shell size 9 plug, 26 AWG wire type "A",
non-std wire length 20 inches with M2 low profile jackscrews.
101 R xxx x - x x x x xx - xxx
Non Std. ꢅength (Inches)
Connector Series
Stranded Wire (no decimal values)
e.g. 1 = 1 inches, 100 = 100 inches
Solid Wire (0.109 < length < 1.00)
e.g. 110 = .110 inches, 999 = .999 inches
101 = all plastic shell
ꢀnsulator Material
ꢁ = Polyphenylene Sulfide (Ryton)
Hardꢆare (pre-installed by factory)
b = standard mounting holes
P = jackpost
Connector Siꢉe (number of contacts)
09, 15, 21, 25, 31, 37, 51
M2 = low profile jackscrew, allen head
M3 = high profile jackscrew, allen head
M5 = low profile jackscrew, slot head
M6 = high profile jackscrew, slot head
ꢅ = captive low profile jackscrew
K = captive high profile jackscrew
f = forward float mount
Connector Type
P = plug (pin)
S = receptacle (socket)
wire Siꢉe (AwG.)
1 = 32
2 = 30
ꢁ = reverse float mount
3 = 28
4 = 26 (M83513 standard) *off shelf
5 = 25 (solid wire only)
6 = 24
wire ꢅength ((inches +1.00/-0.00)
A = 18.00
b = 36.00
Omit for solder cup contacts
C = 72.00
D = 0.500 (solid wire only +0.20/-0.00)
ꢃ = 1.00 (solid wire only +0.20/-0.00)
f = Non std. length (add to end of part no.)
Omit for solder cup contacts
wire Type
General Applications:
A = 7 strd, per NEMA-HP3 (MIL-W-16878/4)
b = 7 strd, per NEMA-HP3 ((MIL-W-16878/6)
C = 19 strd, per NEMA-HP3 (MIL-W-16878/4)
D = 19 strd, per NEMA-HP3 (MIL-W-16878/6)
Military/Aerospace Applications:
ꢃ = per MIL-W-22759/11 (M83513 standard)
f = per MIL-W-22759/33 (space grade)
ꢅ = solid wire uninsulated
wire Color / finish
1 = all white (M83513 standard) *off shelf
2 = all yellow
3 = solid wire uninsulated, tin plated
4 = solid wire uninsulated, gold plated
5 = color coded per mil-std-681, system 1
6 = 1st 10 colors blk. thru wht. repeated
(M83513 standard) *off shelf
Omit for solder cup contacts
Omit for solder cup contacts
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
