PCB Connectors
Series 110 - How to Order
Amphenol
Aerospace
ꢁꢃvꢃꢁSꢃD PꢂꢅAꢁꢀzATꢀꢂN Cbꢁ TꢃꢁMꢀNATꢀꢂN TYPꢃ NAꢁꢁꢂw (90 DꢃGꢁꢃꢃ) PCb
Example:
110RN21P-CBRP1
Description: metal shell size 21 plug, reversed polarization, nickel finish,
CBR termination, PCB tail lead length .109 inches with jackposts included.
110 R x xxx x - CBR x x x - xxx
Non Std. wire ꢅength
(0.109 < length < 1.00)
e.g. 125 = .125 inches
Connector Series
110 = reversed CBR type
metal shell per M83513
ꢅead ꢅength (inches)
1 = .109 .015
ꢀnsulator Material
ꢁ = Polyphenylene Sulfide (Ryton)
2 = .140 .015
3 = .172 .015
4 = .250 .015
f = non std. length (add to end of part no.)
Shell finish
A = anodize
C = cadmium
G = gold
Threaded ꢀnsert (pre-installed)
T = threaded insert (PCB mounting option)
Omit for no threaded insert
ꢀ = irridite/alodine
N = electroless nickel
T = tin
Hardꢆare (pre-installed)
P = jackpost
Connector Siꢉe (number of contacts)
09, 15, 21, 25, 31, 37, 51, 69, 100
Omit for no jackpost
All sizes I.A.W. M83513 except size 69 (non-military)
Termination Type
Cbꢁ = narrow 90 PCB (dimensionally same
Connector Type
P = Plug (pin)
0
as M83513/10 thru /15)
S = Receptacle (socket)
REVERSED POLARIZATION
CBR CONNECTOR
STANDARD
CBR CONNECTOR
POLARIZATION /
"D" SHAPE KEYSTONE
Features
• Polarization is reversed from a standard series 100 CBR type connector.
• Available in sizes 9 thru 100, right angle PCB termination.
• Solid copper 24 AWG PCB leads, tin plated, and solder dipped.
• Wide selection of hardware options.
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
159
