AME, Inc.
AME5134
n
Absolute Maximum Ratings
Parameter
V
IN
, FB, OV to GND
SW to GND
EN, CTRL, SS to GND
ESD Classification
High-Efficiency, 30V Boost
Converters for 2 to 6 White LEDs
Maximum
-0.3 to 6.0
-0.3 to 30
-0.3 to (V
IN
+ 0.3)
B*
Unit
V
Caution: Stree above the listed absolute maximum rating may cause permanent damage to the device.
* HBM B:2000V~3999V
n
Recommended Operating Conditions
Parameter
Ambient Temperature Range
Junction Temperature Range
Storage Temperature Range
Symbol
T
A
T
J
T
STG
Rating
-40 to 85
-40 to 125
-65 to 150
Unit
o
C
n
Thermal Information
Parameter
Thermal Resistance*
(Junction to Case)
Thermal Resistance
(Junction to Ambient)
Internal Power Dissipation
Solder Iron(10 Sec)**
DFN-8
(3mmx3mmx0.75mm)
Conductive
Epoxy
Package
Die Attach
Symbol
θ
JC
θ
JA
P
D
Maximum
17
Unit
o
C/W
125
o
C/W
800
350
mW
o
C
* Measure
θ
JC
on center of molding compound if IC has no tab.
O
** MIL-STD-202G 210F
F
Rev.C.01
5
