Revision 1.02 – April 12, 2007
S5920 – PCI Product: Electrical Characteristics
Data Book
Table 65. Add-On Timings
Functional Operation Range (V = 5.0 V ± 5%, 0°C to 70°C, 50 pF load on outputs for MAX, 0 pF load for MIN)
CC
Symbol
Parameter
Min
Max
Units
Notes
t
t
t
t
t
t
t
12.5
ns
DXFER# Valid from ADCLK Rising Edge
DXFER# Hold from ADCLK Rising Edge
PTADR# Valid from ADCLK Rising Edge
PTADR# Hold from ADCLK Rising Edge
DQ[31:0] Address Valid from ADCLK Rising Edge
DQ[31:0] Hold from ADCLK Rising Edge
DQ[31:0] Address Float from ADCLK Rising Edge
45
3
ns
ns
ns
ns
ns
ns
46
47
48
49
50
51
14
3
3
17.3
16.9
1
1
1
Notes:
1. Refers to Pass-Thru Active mode only.
AMCC Confidential and Proprietary
DS1596
158
