Chapter 1: Cyclone IV Device Datasheet
1–35
Switching Characteristics
Table 1–42 and Table 1–43 list the IOE programmable delay for Cyclone IV E 1.2 V
core voltage devices.
Table 1–42. IOE Programmable Delay on Column Pins for Cyclone IV E 1.2 V Core Voltage Devices (1), (2)
Max Offset
Number
Paths
Affected
Min
Offset
Parameter
of
Fast Corner
I7
Slow Corner
C8
Unit
Setting
C6
A7
C6
C7
I7
A7
Pad to I/O
dataout to
core
Input delay from pin to
internal cells
7
8
2
0
0
0
1.314 1.211 1.211 2.177 2.340 2.433 2.388 2.508 ns
1.307 1.203 1.203 2.19 2.387 2.540 2.430 2.545 ns
0.437 0.402 0.402 0.747 0.820 0.880 0.834 0.873 ns
Input delay from pin to Pad to I/O
input register
input register
I/O output
register to
pad
Delay from output
register to output pin
Input delay from
dual-purpose clock pin clock
to fan-out destinations network
Pad to global
12
0
0.693 0.665 0.665 1.200 1.379 1.532 1.393 1.441 ns
Notes to Table 1–42:
(1) The incremental values for the settings are generally linear. For the exact values for each setting, use the latest version of the Quartus II software.
(2) The minimum and maximum offset timing numbers are in reference to setting 0 as available in the Quartus II software.
Table 1–43. IOE Programmable Delay on Row Pins for Cyclone IV E 1.2 V Core Voltage Devices (1), (2)
Max Offset
Number
Paths
Affected
Min
Offset
Parameter
of
Fast Corner
I7
Slow Corner
C8
Unit
Setting
C6
A7
C6
C7
I7
A7
Pad to I/O
dataout to
core
Input delay from pin to
internal cells
7
8
2
0
0
0
1.314 1.209 1.209 2.201 2.386 2.510 2.429 2.548 ns
1.312 1.207 1.207 2.202 2.402 2.558 2.447 2.557 ns
0.458 0.419 0.419 0.783 0.861 0.924 0.875 0.915 ns
Input delay from pin to Pad to I/O
input register
input register
I/O output
register to
pad
Delay from output
register to output pin
Input delay from
dual-purpose clock pin clock
to fan-out destinations network
Pad to global
12
0
0.686 0.657 0.657 1.185 1.360 1.506 1.376 1.422 ns
Notes to Table 1–43:
(1) The incremental values for the settings are generally linear. For the exact values for each setting, use the latest version of the Quartus II software.
(2) The minimum and maximum offset timing numbers are in reference to setting 0 as available in the Quartus II software.
December 2013 Altera Corporation
Cyclone IV Device Handbook,
Volume 3
