Automotive Grade, Fully Integrated, Hall Effect-Based Linear Current Sensor
with 2.1 kVRMS Voltage Isolation and a Low-Resistance Current Conductor
ACS714
x30A PERFORMANCE CHARACTERISTICS over Range E: TA = –40°C to 85°C1, CF = 1 nF, and VCC = 5 V, unless otherwise specified
Characteristic
Optimized Accuracy Range
Sensitivity
Symbol
Test Conditions
Min.
–30
64
Typ.
Max.
Units
IP
–
30
A
Sens
Over full range of IP, TA = 25°C
66
68
mV/A
Peak-to-peak, TA = 25°C, 66 mV/A programmed Sensitivity,
CF = 47 nF, COUT = open, 2 kHz bandwidth
Noise
VNOISE(PP)
–
7
–
mV
TA = –40°C to 25°C
TA = 25°C to 150°C
TA = –40°C to 25°C
TA = 25°C to 150°C
IP = 0 A
–
–
–0.35
–0.08
0.007
–0.002
–
–
–
mV/°C
mV/°C
mV/A/°C
mV/A/°C
mV
Zero Current Output Slope
∆IOUT(Q)
–
–
Sensitivity Slope
∆Sens
–
–
Electrical Offset Voltage
Total Output Error2
VOE
–30
–
30
–
ETOT
IP = ±30 A, TA = 25°C
±1.5
%
1Device may be operated at higher primary current levels, IP, and ambient temperatures, TA, provided that the Maximum Junction Temperature,
TJ(max), is not exceeded.
2Percentage of IP, with IP = 30 A. Output filtered.
x30A PERFORMANCE CHARACTERISTICS over Range L: TA = –40°C to 150°C1, CF = 1 nF, and VCC = 5 V, unless otherwise specified
Characteristic
Symbol
Test Conditions
Min.
–30
–
Typ.
Max.
Units
Optimized Accuracy Range
IP
–
30
A
Over full range of IP, TA = 25°C
66
–
–
mV/A
mV/A
Sensitivity
Sens
Over full range of IP, TA = –40°C to 150°C
63
69
Peak-to-peak, TA = 25°C, 66 mV/A programmed Sensitivity,
CF = 47 nF, COUT = open, 2 kHz bandwidth
Noise
VNOISE(PP)
–
7
–
mV
TA = –40°C to 25°C
TA = 25°C to 150°C
TA = –40°C to 25°C
TA = 25°C to 150°C
IP = 0 A
–
–
–0.35
–0.08
0.007
–0.002
–
–
–
mV/°C
mV/°C
mV/A/°C
mV/A/°C
mV
Zero Current Output Slope
∆IOUT(Q)
–
–
Sensitivity Slope
∆Sens
VOE
–
–
Electrical Offset Voltage
Total Output Error2
–40
–
40
–
IP = ±30 A, TA = 25°C
±1.5
%
ETOT
IP =±30 A, TA = –40°C to 150°C
–5
–
5
%
1Device may be operated at higher primary current levels, IP, and ambient temperatures, TA, provided that the Maximum Junction Temperature,
TJ(max), is not exceeded.
2Percentage of IP, with IP = 30 A. Output filtered.
