[AK4679]
Addr
1CH
Register Name
Side Tone A Control
R/W
D7
0
R
0
D6
SVAR2
R/W
0
D5
SVAR1
R/W
0
D4
SVAR0
R/W
0
D3
0
R
0
D2
SVAL2
R/W
0
D1
SVAL1
R/W
0
D0
SVAL0
R/W
0
Default
SVAL2-0, SVAR2-0: Side Tone Volume A (SVOLA) (Table 39)
Default: “000” (0dB)
Addr
1DH
1EH
Register Name
D7
0
0
R
0
D6
OVL6
OVR6
R/W
0
D5
OVL5
OVR5
R/W
0
D4
OVL4
OVR4
R/W
0
D3
OVL3
OVR3
R/W
1
D2
OVL2
OVR2
R/W
1
D1
OVL1
OVR1
R/W
0
D0
OVL0
OVR0
R/W
0
Lch Output Volume Control
Rch Output Volume Control
R/W
Default
OVL6-0, OVR6-0: Output Digital Volume (Table 68)
Default: “0CH” (0dB)
Addr Register Name
PCM I/F Power Management
D7
PMMIX
R/W
0
D6
PMSRBO
D5
PMSRBI
D4
PMPCMB
D3
PMOSC
D2
PMSRAO
D1
PMSRAI
D0
PMPCMA
1FH
R/W
Default
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
R/W
0
PMPCMA: PCM I/F A Power Management
0: Power down (default)
1: Power up
PMSRAI: SRCAI Power Management
0: Power down (default)
1: Power up
PMSRAO: SRCAO Power Management
0: Power down (default)
1: Power up
PMOSC: Internal Oscillator Power Management
0: Power down (default)
1: Power up
PMPCMB: PCM I/F B Power Management
0: Power down (default)
1: Power up
PMSRBI: SRCBI Power Management
0: Power down (default)
1: Power up
PMSRBO: SRCBO Power Management
0: Power down (default)
1: Power up
PMMIX: MIX1 Block Power Management
0: Power down (default)
1: Power up
MS1402-E-06
2013/02
- 170 -
