[AK4675]
■ Stereo Line Output (LOUT1/ROUT1 pins)
When DACL and DACR bits are “1”, Lch/Rch signal of DAC is output from the LOUT1/ROUT1 pins which is
single-ended. When DACL and DACR bits are “0”, output signal is muted and LOUT1/ROUT1 pins output VCOM
voltage. The load impedance is 10kΩ (min.). When the PMLO1=PMRO1=LOPS1 bits = “0”, LOUT1/ROUT1 enters
power-down mode and the output is pulled-down to VSS1 by 100kΩ(typ). When the LOPS1 bit is “1”, LOUT1/ROUT1
enters power-save mode. Pop noise at power-up/down can be reduced by changing PMLO1 and PMRO1 bits at LOPS1
bit = “1”. In this case, output signal line should be pulled-down to VSS1 by 20kΩ after AC coupled as Figure 64. Rise/Fall
time is 300ms(max) at C=1μF and AVDD=3.3V. When PMLO1=PMRO1 bits = “1” and LOPS1 bit = “0”,
LOUT1/ROUT1 is in normal operation.
L1VL2-0 bits control the volume of LOUT1/ROUT1.
When LOM bit = “1”, DAC output signal is output to LOUT1 and ROUT1 pins as (L+R) mono signal.
When LOOPM bit = “1”, the MIC-Amp signal is output to LOUT1 and ROUT1 pins as (L+R) mono signal.
LOPS1
0
PMLO1
Mode
LOUT1 pin
0
1
0
1
Power-down
Normal Operation
Power-save
Pull-down to VSS1
Normal Operation
Fall down to VSS1
Rise up to VCOM
(default)
(default)
1
Power-save
Table 65. Stereo Line Output Mode Select (LOUT1)
LOPS1
0
PMRO1
Mode
ROUT1 pin
0
1
0
1
Power-down
Normal Operation
Power-save
Pull-down to VSS1
Normal Operation
Fall down to VSS1
Rise up to VCOM
1
Power-save
Table 66. Stereo Line Output Mode Select (ROUT1)
L1VL2-0
6H
Attenuation
+6dB
5H
0dB
(default)
4H
−6dB
3H
2H
1H
0H
−12dB
−18dB
−24dB
MUTE
Table 67. Stereo Line Output Volume Setting
LOUT1
ROUT1
1μF
220Ω
20kΩ
Figure 64. External Circuit for Stereo Line Output (in case of using Pop Noise Reduction Circuit)
