[AK4675]
SBMX1-0 bits set the data mixing from SDTIA input and SVOLB output. The mixed data is output to SDTOB via
DATT-C.
SBMX1
SBMX0
DATT-C Input
SDTIA
SVOLB
(SDTIA) + (SVOLB)
N/A
0
0
1
1
0
1
0
1
(default)
Table 57. SDTOB Mixing (N/A: Not available)
When SDOBD bit is “1”, SDTOB output data can be disabled (fixed to “L”).
SDOBD
SDTOB
0
1
Enable (Output) (default)
Disable (“L”)
Table 58. SDTOB Disable
BVMX1-0 bits set the data mixing for SRC-B from SDTIA input (DATT-B output) and SDTIB input (BIVOL output).
BVMX1
BVMX0
SRC-B Input
SDTIA
SDTIB
(SDTIA) + (SDTIB)
N/A
0
0
1
1
0
1
0
1
(default)
Table 59. SRC-B Input Mixing (N/A: Not available)
