7
HFBR-15X1 Transmitter
8 DO NOT CONNECT
ANODE
CATHODE
N.C.
N.C.
1
2
3
4
5 DO NOT CONNECT
Pin #
1
2
3
4
5
8
Function
Anode
Cathode
Open
Open
Do not connect
Do not connect
Note:
Pins 5 and 8 are for mounting and
retaining purposes only. Do not
electrically connect these pins.
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Temperature
Lead Soldering Cycle
Forward Input Current
Reverse Input Voltage
Symbol
T
S
T
A
Temp.
Time
I
FPK
I
Fdc
V
BR
Min.
–40
–40
Max.
+85
+85
260
10
1000
80
5
Units
°C
°C
°C
sec
mA
V
Reference
Note 1
Note 2, 3
Notes:
1. 1.6 mm below seating plane.
2. Recommended operating range between 10 and 750 mA.
3. 1
µs
pulse, 20
µs
period.
All HFBR-15XX LED transmitters are classified as IEC 825-1 Accessible
Emission Limit (AEL) Class 1 based upon the current proposed draft scheduled
to go into effect on January 1, 1997. AEL Class 1 LED devices are considered
eye safe. Contact your local Agilent sales representative for more information.
