Agilent HCPL-354
AC Input Phototransistor
Optocoupler
SMD Mini-Flat Type
Data Sheet
Features
•
•
AC input response
Current transfer ratio
(CTR: min. 20% at I = ± 1 mA,
F
V
= 5 V)
CE
•
•
Isolation voltage between input
Description
The HCPL-354 contains a
Ordering Information
Specify Part Number followed by
Option Number (if desired).
and output (V = 3,750 V
)
rms
iso
phototransistor, optically coupled to
two light emitting diodes connected
inverse parallel. It can operate
directly by AC input current. It is
packaged in a 4-pin mini-flat SMD
package with a 2.0 mm profile. The
small dimension of this product
allows significant space saving. The
package volume is 30% smaller than
that of conventional DIP type. Input-
Subminiature type
(The volume is smaller than that of
conventional DIP type by as far as
30%)
HCPL-354-XXXE
Lead Free
Option Number
•
•
•
•
•
Mini-flat package
2.0 mm profile
UL approved
000 = No Options
060 = IEC/EN/DIN EN 60747-5-2
Option
CSA approved
IEC/EN/DIN EN 60747-5-2
approved
output isolation voltage is 3750 V
Response time, t , is typically 4 µs
and minimum CTR is 20% at input
current of ± 1 mA.
.
00A = Rank Mark A
rms
r
•
Options available:
– IEC/EN/DIN EN 60747-5-2
approvals (060)
Functional Diagram
Applications
1
2
4
3
•
•
•
•
Detecting or monitoring AC signals
Programmable controllers
AC/DC-inputmodules
AC line/digital logic isolation
1. ANODE, CATHODE
2. CATHODE, ANODE
3. EMITTER
4. COLLECTOR
CAUTION: It is advised that normal static precautions be taken in handling and assembly of this component to
prevent damage and/or degradation which may be induced by ESD.
