Tools
Multisim
NI Multisim™ Component Evaluator Analog Devices Edition is a free, downloadable version of National Instruments Multisim 11 circuit simulation software,
tailored for evaluating ADI components. The software abstracts away the complexities of traditional SPICE simulation through intuitive analysis instruments
and interactive circuit components for a highly graphical approach to design. It also combines a powerful mixed-mode simulation parser and an extensive
collection of analyses. It offers a holistic approach to component evaluation. SPICE models, online example circuits, and data sheets are all connected
through a single evaluation environment. Visit www.analog.com/multisim.
Features and Benefits
•ꢀBuild simulated circuits with a library of Analog
Devices operational amplifiers, switches, and voltage
references
•ꢀSimulate better with SPICE parser improvements,
updated BSIM models, support for advanced
parameters, and enhanced digital simulation accuracy
•ꢀImproved design communication with on-page
connectors and a new WYSIWYG net naming system
ADI DiffAmpCalc
ADI DiffAmpCalc™ performs all the required differential amplifier calculations, which reduces design risks and further speeds time to market. In addition,
designers can quickly and easily calculate gain and component values of a differential amplifier circuit for terminated or unterminated loads, determine
the input/output and VOCM voltage range, as well as calculate noise and power dissipation. The tool also prevents you from making mistakes by alerting
you when a device parameter has been exceeded. Visit www.analog.com/diffampcalc.
Features and Benefits
•ꢀAutomate time-consuming calculations required to
determine optimal levels for gain, termination resistors,
power dissipation, noise output and input common-
mode voltage range
•ꢀCreate unlimited “what if” scenarios as data changes
appear in real-time
•ꢀIntuitive GUI features an interactive dashboard.
•ꢀUse a “point and click” method for quickly and easily
adding and changing data
•ꢀSupports ADI’s differential amplifier products including
ADA4927, ADA4932, ADA4937, ADA4938, ADA4939,
AD8132, AD8137, AD8138, AD8139, and ADA4930
