16.3. Functional Description
The ARM Cortex-M0 microcontroller core is configured for little endian operation and includes the fast single-cycle 32-bit
multiplier and 24-bit SysTick timer and can operate at a frequency of up to 50MHz.
The microcontroller nested vectored interrupt controller (NVIC) supports 25 external interrupts for the device's peripherals
and sub-systems. For low-latency interrupt processing, the NVIC also supports interrupt tail-chaining. The wake-up
interrupt controller (WIC) is able to wake up the device from low-power modes using any GPIO interrupt, as well as from
the RTC or WDT. The ARM Cortex-M0 supports both sleep and deep-sleep low-power modes. The deep-sleep mode
supports clock gating to limit standby power even further.
Firmware debug support includes 4 break-point and 2 watch-point unit comparators using the serial wire debug (SWD)
protocol. The serial wire debug mechanism can be disabled to prevent device access to the firmware in the field.
