ACT8865
Rev 7, 22-Mar-16
ORDERING INFORMATION
TEMPERATURE
PART NUMBER
VOUT1
VOUT2
VOUT3 VOUT4 VOUT5 VOUT6 VOUT7 PACKAGE PINS
RANGE
ACT8865QI305-T
1.8V
1.2V
1.2V
3.3V 2.5V 3.3V OFF OFF TQFN44-32 32
3.3V 2.5V 3.3V OFF OFF TQFN44-32 32
-40°C to +85°C
ACT8865QI405-T 1.5V/1.35V
-40°C to +85°C
: All Active-Semi components are RoHS Compliant and with Pb-free plating unless specified differently. The term Pb-free means
semiconductor products that are in compliance with current RoHS (Restriction of Hazardous Substances) standards.
: Standard product options are identified in this table. Contact factory for custom options, minimum order quantity is 12,000 units.
: To select VSTBYx as a output regulation voltage of REGx, drive VSEL to a logic high. The VSTBYx can be set by software via I2C
interface, refer to appropriate sections of this datasheet for VSTBYx setting.
: VOUT2 = 1.2V @VSEL=0 and VOUT2 = 1.0V @VSEL=VIN
: VOUT1 = 1.35V @VSEL=VIN and VOUT1 = 1.5V @VSEL=0 for ACT8865QI405-T regulator setting.
PIN CONFIGURATION
TOP VIEW
Thin - QFN (TQFN44-32)
