ISD5100 – SERIES
7.4.6. Ana Out Description
*FTHRU
*INP
(1 Vp-p max. from AUX INor ARRAY)
( 69 4 mV p-p max . fr o m mi cr ophone input)
*VOL
Chip Set
AN A OU T +
AN A OU T –
*FILTO
*SUM1
*SUM2
1
(AOPD)
AOPD
0
1
CONDITION
Power Up
Power Down
3 (AOS2,AOS1,AOS0)
AOS2
AOS1 AOS0 SOURCE
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
FTHRU
INP
VOL
FILTO
SUM1
SUM2
N/C
*DIFFERENTIAL PATH
N/C
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
AI G1
AIG0 AIPD AXG1 AXG0 AXPD INS0 AOS2 AOS1 AOS0 AOPD OPS1 OPS0 OPA1 OPA0 VLPD CFG0
7.4.7. Analog Inputs
Microphone Inputs
The microphone inputs transfer the voice signal to the on-chip AGC preamplifier or directly to the ANA
OUT MUX, depending on the selected path. The direct path to the ANA OUT MUX has a gain of 6
dB so a 208 mV p-p signal across the differential microphone inputs would give 416 mV p-p across
the ANA OUT pins. The AGC circuit has a range of 45 dB in order to deliver a nominal 694 mV p-p
into the storage array from a typical electric microphone output of 2 to 20 mV p-p. The input
impedance is typically 10kΩ.
The ACAP pin provides the capacitor connection for setting the parameters of the microphone AGC
circuit. It should have a 4.7 µF capacitor connected to ground. It cannot be left floating. This is
because the capacitor is also used in the playback mode for the AutoMute circuit. This circuit reduces
the amount of noise present in the output during quiet pauses. Tying this pin to ground gives
maximum gain; to VCCA gives minimum gain for the AGC amplifier but will cancel the AutoMute
function.
