1-1 Power Management ICs
1-1-1 Power Factor Correction (PFC) ICs
Control ICs
●Continuous Conduction Mode (CCM) PFC Control IC
For high power and high efficiency applications, with brown-in and brown-out functions
Series Name
SSC2000
Part Number
SSC2001S
Oscillation Frequency
Fixed to 65kHz
Package
SOP8
●Interleaved Discontinuous Conduction Mode (DCM) PFC Control IC
8-pin package, minimum number of discrete components, low noise, and low ripple
Series Name
SSC2100
Part Number
SSC2101S
Maximum on-time
Package
SOP8
15µs
1-1-2 AC/DC Converter ICs
●PWM type
<STR-A6000 Series>
• For small power applications
• Low noise, low standby power
• Brown-in and brown-out functions
Part Number
STR-A6051M
Oscillation Frequency
67kHz
MOSFET VDSS
650V
RDS(ON)
3.95Ω
2.8Ω
Package
DIP8
STR-A6052M
STR-A6053M
STR-A6059H
STR-A6062H
STR-A6069H
STR-A6079M
67kHz
650V
67kHz
650V
1.9Ω
100kHz
650V
6.0Ω
100kHz
700V
2.8Ω
100kHz
700V
6.0Ω
67kHz
800V
19.2Ω
<STR-V600 Series>
• Low height, at least 4 mm of creepage isolation between high and low terminal tips
• Low noise, low standby power
• SIP8 package version of STR-A6000
Part Number
STR-V653
Oscillation Frequency
67kHz
MOSFET VDSS
650V
RDS(ON)
Package
SIP8
1.9Ω
<STR-W6000S Series>
• Low noise, low standby power
• Brown-in and brown-out functions
Part Number
STR-W6051S
STR-W6052S
STR-W6053S
Oscillation Frequency
MOSFET VDSS
650V
RDS(ON)
3.95Ω
2.8Ω
Package
67kHz
67kHz
67kHz
650V
TO220F-6
650V
1.9Ω
<STR-W6200D Series>
• Low noise, low standby power
• External latch protection (ELP) function
Part Number
STR-W6251D
STR-W6252D
STR-W6253D
Oscillation Frequency
MOSFET VDSS
650V
RDS(ON)
3.95Ω
2.8Ω
Package
67kHz
67kHz
67kHz
650V
TO220F-6
650V
1.9Ω
ICs
6
