Global Mixed-mode Technology Inc.
G936
C
D
L
E
H
e
θ1
A
A2
A1
b
SOT-23 (T7) Package
Note:
1.Package body sizes exclude mold flash protrusions or gate burrs
2.Tolerance ±0.1000 mm (4mil) unless otherwise specified
3.Coplanarity: 0.1000mm
4.Dimension L is measured in gage plane
DIMENSIONS IN MILLIMETERS
SYMBOLS
MIN
1.00
0.00
0.70
0.35
0.10
2.70
1.40
-----
2.60
0.37
1º
NOM
1.10
MAX
A
A1
A2
b
C
D
1.30
0.10
0.90
0.50
0.25
3.10
1.80
-----
3.00
-----
9º
-----
0.80
0.40
0.15
2.90
1.60
E
e
H
L
1.90(TYP)
2.80
------
5º
θ1
