Three seven segment LED displays provide drive programming, status and
diagnostic values. Refer to the following tables for further information:
• Table 5.1 for User Adjustable Parameters description (pages 5-1 and 5-2).
• Table 5.2 for Drive Status description (page 5-5).
• Table 5.3 for Diagnostics information (page 5-6).
)81&7,21#.(<6
The Function Keys are used to navigate around the Man Machine Interface (MMI)
structure as well as control the drive if LOCAL MODE is selected (See Chapter 5).
The MMI “Tree” structure and function key operation is described in the following
diagram.
STATUS LEVEL
M
E
TITLE
LEVEL
3ëç
ë
ê
é
3ë 3êûîîîûîîîûîîîû3ëç
ë
M
E
Current parameter values are displayed.
Diagnostic values.
Display only.
VALUE
LEVEL
Use
parameter values.
to increase/decrease
MENU
M
This key is used to descend from STATUS LEVEL to TITLE LEVEL or from
TITLE LEVEL to VALUE LEVEL.
(Red)
This function key is also used to stop the drive when LOCAL mode is selected.
ESCAPE
E
This key is used to ascend from VALUE LEVEL to TITLE LEVEL or from
TITLE LEVEL to STATUS LEVEL. Note this action saves the selected
parameter.
(Green)
This function key is also used to start the drive when LOCAL mode is selected.
UP
This key is used to scroll through the TITLE LEVEL or increase parameter
values.
This function key is also used to increase the local setpoint and thus the
inverter frequency when LOCAL mode is selected
DOWN
This key is used to scroll through the TITLE LEVEL or to decrease parameter
values. This function key is also used to decrease the local setpoint and thus
the inverter frequency when LOCAL mode is selected.
