Right Angle Plug Crimp Attachment for Flexible Cable and Direct Solder for Semi-Rigid Cable
Right Angle Solder Plug - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
B1182A1-N/3GT3G-10-50
B1182A1-N/NT30GA-11-50
10
11
Nickel/Gold Teflon
Nickel/Gold Teflon
50
50
N/A
N/A
Assembly Instruction F - page 214
Right Angle Crimp/Crimp Plug - Standard Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
Brass Shell
B1122A1-ND3G-1-50
B1122A1-ND3G-3-50
B1122A1-ND3G-3-75
B1122A1-NT3G-8-75
B1122A1-NT3G-15-75
01
03
03
08
15
Nickel
Nickel
Nickel
Nickel
Nickel
Delrin
Delrin
Delrin
Teflon
Teflon
50
50
75
75
75
4
4
4
5
5
Diecast Shell
B1122B1-001-ND3G-1-50
B1122B1-001-ND3G-3-75
B1122B1-001-NT3G-75
01
03
16
Nickel
Nickel
Nickel
Delrin
Delrin
Teflon
50
75
75
3 or 4
4
.180 hex
Assembly Instruction S - page 227
Right Angle Crimp/Crimp Plug - Miniature Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
Brass Shell
B1122E1-002-ND3G-5-50
B1122E1-ND3G-6-75
05
06
Nickel
Nickel
Delrin
Delrin
50
75
3
3
Diecast Shell
B1122F1-001-ND3G-5-50
B1122F1-001-ND3G-6-75
05
06
Nickel
Nickel
Delrin
Delrin
50
75
3
3
Remark: With teflon sleeve Hex. crimp size .178”
Assembly Instruction S - page 227
73
For Reversed Polarized connectors contact local Amphenol Sales Branch.
